3. INSPECTION/ADJUSTMENT
3-1
PEOPLE S 4T
SERVICE INFORMATION
GENERAL
！ WARNING
•Before running the engine, make sure that the working area is well-ventilated. Never run the
engine in a closed area. The exhaust contains poisonous carbon monoxide gas which may
cause death to people.
•Gasoline is extremely flammable and is explosive under some conditions. The working area
must be well-ventilated and do not smoke or allow flames or sparks near the working area or
fuel storage area.
SPECIFICATIONS
ENGINE
Throttle grip free play : 2～6mm
Spark plug gap : 0.6～0.7mm
Spark plug: Standard : NGK C7HSA
Valve clearance : IN: 125/200cc 0.12mm 50cc 0.04mm
EX: 125/200cc 0.12mm 50cc 0.04mm
Idle speed : 1700±100rpm
Engine oil capacity:
At disassembly : 125/200cc 1.1 liter, 50cc 0.85 liter
At change : 125/200cc 0.9 liter, 50cc 0.7 liter
Gear oil capacity :
At disassembly : 125/200cc 210cc, 50cc 120cc
At change : 125/200cc 180cc, 50cc 90cc
Cylinder compression ( 125/200/50 ) : ( 13/15/18 )kg/cm
2
Ignition timing : BTDC 15°~28°±2°/1700±100rpm
BODY
Front brake free play: 10～20mm
Rear brake free play: 10～20mm
TIRE PRESSURE
1 Rider 2 Riders
Front 1.75kg/cm
2
1.75kg/cm
2
Rear 2.00kg/cm
2
2.25kg/cm
2
TIRE SIZE:
Front : 80/80-16 45P, 50cc 100/80-16 M/C 50P
Rear : 100/80-16 56P, 50cc 11/70-16 M/C 52P
TORQUE VALUES
Front axle nut 6.0kg-m
Rear axle nut 11.0kg-m
