KYMCO PEOPLE S 125 Service Manual

2. EXHAUST MUFFLER/FRAME COVERS
2-6
PEOPLE S 4T
HANDLEBAR COVER REMOVAL
First remove the windshield.
Remove the four screws and two bolts
attaching the handlebar rear cover.
Remove the handlebar rear cover.
The installation sequence is the reverse of
removal.
Remove the three nuts attaching the
handlebar cover
Remove the handlebar cover.
The installation sequence is the reverse of
removal.
BOTTOM COVER REMOVAL
Remove the four bolts attaching the bottom
cover.
Remove the bottom cover.
EXHAUST MUFFLER REMOVAL
Remove two lock nuts from joint in the
exhaust muffler.
Remove the exhaust muffler two lock bolts to
remove the exhaust muffler.
Remove the exhaust muffler joint packing
collar.
The installation sequence is the reverse of
removal.
Torque:
Exhaust muffler joint lock nut: 2.2kg-m
Exhaust muffler lock bolt: 3.3kg-m
Screws
Handlebar Cove
r
Bolt
Lock Bolts
Bolts
Bolts
Bottom Cove
r
Lock Nut

KYMCO PEOPLE S 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Cooling System	Air Cooled
Max Torque	10.4 Nm @ 6500 rpm
Transmission	CVT
Front Brake	Disc
