Lennox Harmony III Installation Instructions

AIR HANDLERS
Page 42
505023M 08/11
Harmony IIIt Installation Setup Worksheets (continued)
CBX32MV/CBX40UHV – Cooling Only or Cooling with Hot Water Coil (non−Heat Pump)
Job Name: Indoor Unit Model: Outdoor Unit Model:
CBX40UHV and CBX32MV Revision 06 Indoor Unit setup:
- Cut on−board link R to DS DEHUM or HARMONY"
- For Hot Water Coil OnlyAdd K212 Relay & wire per Harmony III wiring detail.
NOTE − Discharge air sensor must be located down stream of cooling coil and hot water coil.
- Air Handler Control jumper settings:
COOL: This setting, along w/ ADJUST setting, determines maximum system CFM (See blower tables)
ADJUST: Setting affects both heating and cooling blower speeds (see blower tables to determine setting)
HEAT: HIGH Heating blower speed selectioin – Ignored by Harmony III
DELAY: 4 Cooling blower ramping – Ignored by Harmony III
BLOWER ONLY CFM: Continuous fan speed – Ignored by Harmony III
EVENHEAT: EVENHEAT is not used with Harmony III
CBX32MV prior to Revision 06 Indoor Unit setup:
- Remove DS to Y1 jumper
- For Hot Water Coil OnlyAdd K212 Relay & wire per Harmony III wiring detail.
NOTE − Discharge air sensor must be located down stream of cooling coil and hot water coil.
- BDC3 control clip jumper settings:
COOL: This setting, along w/ ADJUST setting, determines maximum system CFM (See blower tables)
ADJUST: Setting affects both heating and cooling blower speeds (see blower tables to determine setting)
HEAT: 4 Heating blower speed selectioin – Ignored by Harmony III
DELAY: 4 Cooling blower ramping – Ignored by Harmony III
Harmony IIIt Panel setup:
- Heating staging jumper (circle one): 85 90 100 110 120 130 (Cooling only – setting does not matter; Hot water − set at 120)
- Zone 1 PIAB 140F DAS jumper in place (circle one): Yes No (Cooling only – setting does not matter)
- Cooling staging jumper (circle one): 50 55 60 (select desired discharge air temp during cooling–50 deg−F suggested)
- Cont. Air Reduction jumper (circle one): 0 25 50 75 (% airflow reduction for continuous fan operation)
- Heating Air Reduction jumper (circle one): 0 20 40 ( Cooling only – setting does not matter; Hot Water set at % reduction for Heating mode)
- System Configuration jumpers (circle one): HP GAS (Set to GAS)
- Stages (circle one): 2COOL 1COOL (Set to match condenser, 1 or 2 stage)
- Stages (circle one): 2HP 1HP (ignored; non−heat pump application – setting does not matter)
- E−HEAT Stages (circle one): DF 1 2 3 (non−heat pump – setting does not matter )
- Desired total system cfm with all zones calling ___________ cfm, Actual total system cfm− ___________
- CB unit minimum" cfm ____________ (determined by unit spec listed below unit blower table)
- Zone 1 – Desired cfm ____________ PIAB Setting ____________% Actual cfm ____________
- Zone 2 – Desired cfm ____________ PIAB Setting ____________% Actual cfm ____________
- Zone 3 – Desired cfm ____________ PIAB Setting ____________% Actual cfm ____________
- Zone 4 – Desired cfm ____________ PIAB Setting ____________% Actual cfm ____________
NOTEAll of the above are recommended starting positions for DIP switches and Harmony III jumpers. Slight variations may be required during sys-
tem start up and operation checks.
Field Wiring Checklist:
- Indoor Unit Wiring Completed:
- DS" on Harmony III to DS" on indoor unit connected,
- "C" on indoor unit connected to Harmony III transformer C",
- No connection to Y1" or Y2" on indoor unit.
- Outdoor Unit Wiring Completed.
- Thermostat and Damper Wiring Completed.
- Discharge Sensor wired to Harmony III and if a hot water coil is used, the sensor must be located down stream of the hot water coil.
