Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 123
7 Drive application
7.1 Parameterisation dialog
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
 Tip!
When you click the Signal flow button, you will get one dialog level down to the signal flow
of the application.
L_MPot_1: Use
(C806)
0: No Alternatively, the main speed setpoint can be generated
via a motor potentiometer function.
• In the Lenze setting, the motor potentiometer func-
tion is deactivated.
• Activation is possible via C806
or via the
bMPotEnable input.
• The behaviour of the motor potentiometer during
switch-on of the drive system can be selected in
C805
.
• For a detailed functional description see
FB L_MPot_1
. ( 305)
Accel. time - main setpoint
(C012)
2.0 s The setpoint is led via a ramp function generator with li-
near characteristic. The ramp function generator con-
verts setpoint step-changes at the input into a ramp.
• For a detailed functional description see
FB L_NSet_1
. ( 309)
Decel. time - main setpoint
(C013)
2.0 s
Reference speed
(C011)
1500 rpm All speed setpoint selections are provided in % and al-
ways refer to the reference speed set in C011
.
The motor reference speed is given on the motor name-
plate.
Deceleration time - quick
stop
(C105)
5.0 s When "quick stop" is requested, the motor control is de-
coupled from the setpoint selection and within the de-
celeration time parameterised in C105
, the motor is
brought to a standstill in (n
act
=0).
Activate/Deactivate quick stop
( 50)
Fixed setpoint 1
(C039/1)
40.0 % A fixed setpoint for the setpoint generator can be acti-
vated instead of the main setpoint via the selection in-
puts bJogSpeed1 and bJogSpeed2.
• The fixed setpoints are selected in [%] based on the
reference speed (C011
).
• For a detailed functional description see
FB L_NSet_1
. ( 309)
Fixed setpoint 2
(C039/2)
60.0 %
Fixed setpoint 3
(C039/3)
80.0 %
Parameter Lenze setting Info
Value Unit
