Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 303
10 Parameter reference
10.3 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00389 PDO valid / invalid 24186 5E7A A 4 UNSIGNED_8 1
C00409
LP_CanIn Mapping 24166 5E66 A 8 UNSIGNED_16 1
C00443
DIx: Level 24132 5E44 A 2 UNSIGNED_16
C00444
DOx: Level 24131 5E43 A 2 UNSIGNED_16
C00470
LS_ParFree_b 24105 5E29 A 16 UNSIGNED_8 1
C00472
LS_ParFree_a 24103 5E27 A 4 INTEGER_16 100
C00480
LS_DisFree_b 24095 5E1F E 1 UNSIGNED_8
C00481
LS_DisFree 24094 5E1E A 4 UNSIGNED_16
C00482
LS_DisFree_a 24093 5E1D A 4 INTEGER_16 100
C00516
Checksums 24059 5DFB A 1 UNSIGNED_32 1
C00517
User menu 24058 5DFA A 20 INTEGER_32 1
C00565
Resp. to mains phase failure 24010 5DCA E 1 UNSIGNED_8 1
C00574
Resp. to brake resist. overtemp. 24001 5DC1 E 1 UNSIGNED_8 1
C00581
Resp. to LS_SetError_x 23994 5DBA A 2 UNSIGNED_8 1
C00592
Resp. to CAN bus connection 23983 5DAF A 5 UNSIGNED_8 1
C00593
Resp. to CANx_IN monitoring 23982 5DAE A 2 UNSIGNED_8 1
C00594
Resp. to control word error 23981 5DAD A 1 UNSIGNED_8 1
C00598
Resp. to open circuit AINx 23977 5DA9 A 1 UNSIGNED_8 1
C00600
Resp. to DC bus undervoltage 23975 5DA7 A 1 UNSIGNED_8 1
C00601
Del. resp.to fault: DC bus overvoltage 23974 5DA6 A 1 UNSIGNED_16 1000
C00604
Resp. to device overload (Ixt) 23971 5DA3 E 1 UNSIGNED_8 1
C00606
Resp. to motor overload (I²xt) 23969 5DA1 E 1 UNSIGNED_8 1
C00620
16-bit system connection 23955 5D93 A 27 UNSIGNED_16 1
C00621
Bool system connection 23954 5D92 A 61 UNSIGNED_16 1
C00700
LA_NCtrl: Analog connection list 23875 5D43 A 9 UNSIGNED_16 1
C00701
LA_NCtrl: Digital connection list 23874 5D42 A 18 UNSIGNED_16 1
C00725
Current switching frequency 23850 5D2A E 1 UNSIGNED_8 1
C00727
LS_Keypad: Digital values 23848 5D28 A 5 UNSIGNED_8 1
C00728
LS_Keypad: Keypad analog values 23847 5D27 A 3 INTEGER_16 100
C00800
L_MPot_1: Upper limit 23775 5CDF E 1 INTEGER_16 100
C00801
L_MPot_1: Lower limit 23774 5CDE E 1 INTEGER_16 100
C00802
L_MPot_1: Acceleration time 23773 5CDD E 1 UNSIGNED_16 10
C00803
L_MPot_1: Deceleration time 23772 5CDC E 1 UNSIGNED_16 10
C00804
L_MPot_1: Inactive function 23771 5CDB E 1 UNSIGNED_8 1
C00805
L_MPot_1: Init function 23770 5CDA E 1 UNSIGNED_8 1
C00806
L_MPot_1: Use 23769 5CD9 E 1 UNSIGNED_8 1
C00830
16-bit analog input 23745 5CC1 A 11 INTEGER_16 100
C00831
16-bit common input 23744 5CC0 A 1 UNSIGNED_16
C00833
8-bit input 23742 5CBE A 24 UNSIGNED_8 1
C00866
CAN input words 23709 5C9D A 8 UNSIGNED_16
C00868
CAN output words 23707 5C9B A 8 UNSIGNED_16
C00909
Speed limitation 23666 5C72 A 2 INTEGER_16 100
C00910
Frequency limitation 23665 5C71 A 2 UNSIGNED_16 1
C00990
Flying restart fct.: Activation 23585 5C21 E 1 UNSIGNED_8 1
C00991
Flying restart fct.: Process 23584 5C20 E 1 UNSIGNED_16 1
C00992
Flying restart: Start frequency 23583 5C1F E 1 INTEGER_16 1
C00994
Flying restart fct.: Current 23581 5C1D E 1 INTEGER_16 100
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
