DEVICE TESTS
Flash test
This menu item appears only if the flash card is installed. Data is written to the flash card and read back to check the
accuracy.
Warning—Potential Damage: This test deletes all data stored on the flash device. After the test is over, reformat the
flash using Format Flash in the customer Utilities Menu.
To run the Flash Test:
1 Select DEVICE TESTS from Diag Menu, and press Select.
2 Select Flash Test, and press Select.
Contents will be lost. Continue? appears.
3 To continue, select Yes, and press Select. To end the test, select No, and press Select.
If you continue, Flash Test Testing… appears.
• If the test is successful, then Flash Test Test Passed appears. Use Format Flash in the Utilities Menu
to reformat the flash card
• If the test is unsuccessful, then Flash Test Test Failed appears. Replace the flash card.
4 Press Back to remove the message and return to the Device Tests menu.
PRINTER SETUP
• “Defaults” on page 177
• “PAGE COUNTS” on page 178
• “Serial Number” on page 178
• “Engine Setting 1 through 4” on page 178
• “Model Name” on page 178
• “Configuration ID” on page 178
• “Transfer Module Barcode” on page 179
• “Reset Fuser Count” on page 179
Defaults
This setting is used by the printer to determine whether US or non-US factory default values should be used. The
following printer settings have different US and non-US values:
Printer default values US value Non-US value
Paper Sizes setting in the General Settings menu U.S. Metric
Default Paper Size (paper feeding sources which do not
have hardware size sensing capabilities)
Letter A4
Default Envelope Size (envelope feeding sources which do
not have hardware size sensing capability)
10 Envelope DL Envelope
Fax media size Letter A4
7527
Service menus
177
