Lexmark CX310dn Service Manual

Part number index
P/N Part name Page
3049485 Field relocation package assembly.........................................................................................................347
40X0269 Power cord, 2.5 m (straight): USA, Canada, APG, LAD...........................................................................341
40X0271 Power cord, 2.5 m (straight): United Kingdom......................................................................................341
40X0273 Power cord, 2.5 m (straight): Chile, Uruguay, Italy................................................................................341
40X0275 Power cord, 2.5 m (straight): Israel........................................................................................................341
40X0288 Power cord, 2.5 m (straight): Argentina.................................................................................................341
40X0301 Power cord, 2.5 m (straight): Australia..................................................................................................341
40X0303 Power cord, 2.5 m (straight): PRC..........................................................................................................341
40X0411 Narrow media flag..................................................................................................................................333
40X1368 USB Cable, packaged (2 m).....................................................................................................................347
40X1766 Power cord, 2.5 m (straight): Bolivia, Peru............................................................................................341
40X1772 Power cord, 2.5 m (straight): Switzerland..............................................................................................341
40X1773 Power cord, 2.5 m (straight): South Africa.............................................................................................341
40X1774 Power cord, 2.5 m (straight): Denmark..................................................................................................341
40X1791 Power cord, 2.5 m (straight): Taiwan.....................................................................................................341
40X1792 Power cord, 2.5 m (straight): Korea.......................................................................................................341
40X2252 Redrive spacer screws............................................................................................................................330
40X3141 Power cord, 2.5 m (straight): Paraguay, Europe, Middle East, Indonesia, Africa (HV)...........................341
40X3609 Power cord, 2.5 m (straight): Japan.......................................................................................................341
40X4596 Power cord, 2.5 m (straight): Brazil........................................................................................................341
40X5168 Pick tires.........................................................................................................................................328, 346
40X5413 Fuser exit sensor....................................................................................................................................340
40X5414 Toner density sensors, left or right (one in package).............................................................................344
40X5429 Transfer module paper path thermistor................................................................................................344
40X5480 USB cable (CX510)..................................................................................................................................336
40X5480 USB thumbdrive cable (CX510)..............................................................................................................330
40X5490 Front middle cover.................................................................................................................................328
40X5872 Bin full flag..............................................................................................................................................330
40X6243 Flatbed cushion......................................................................................................................................330
40X6247 Simplex separator pad assembly............................................................................................................330
40X6517 Speaker...........................................................................................................................................337, 341
40X7046 Waste toner bottle sensor.....................................................................................................................
344
7527
Part number index
381

Lexmark CX310dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	11.5 s
Time to first page (color, normal)	12.5 s
Print speed (black, normal quality, A4/US Letter)	23 ppm
Duplex print speed (black, normal quality, A4/US Letter)	12 ppm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	copy, print, scan
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	60000 pages per month
Recommended duty cycle	500 - 5000 pages per month
Number of print cartridges	5
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Copier resize	25 - 400 %
Copy speed (black, normal quality, A4)	23 cpm
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Scan speed (color)	32 ppm
Optical scanning resolution	600 x 1200 DPI
Total input capacity	251 sheets
Total output capacity	150 sheets
Maximum input capacity	901 sheets
Total number of input trays	1
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Black, Grey
Display diagonal	2.4 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Internal memory	512 MB
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound power level (standby)	16 dB
Sound pressure level (copying)	48 dB
Sound pressure level (printing)	47 dB
Sound pressure level (scanning)	49 dB
Sound pressure level (duplex printing)	50 dB
Power consumption (average operating)	- W
Package depth	594 mm
Package height	567 mm
Package weight	31430 g
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	Fedora 14, Fedora 15, RedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, RedHat EL Linux 5.1, RedHat EL Linux 5.2, RedHat EL Linux 5.3, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64

Weight and Dimensions

Depth	558 mm
Width	444 mm
Height	470 mm
Weight	27390 g
