Lexmark Optra T User Manual

PCL
2-9
Optra T610, Optra T612, Optra T614, and Optra T616
The following table lists page sizes and print area dimensions for all paper and
envelope sizes the Optra T family of printers supports. For more information about the
printable areas and logical pages for PCL emulation, see “Printable Areas” on
page 2-2.
Note: The explanation of the printable area assumes the
Print Area menu item is set
to Normal. For more information about Print Area, see page 2-11.
Table 2-6: Optra T Family Paper and Envelope Dimensions
Selection
Paper/
Envelope Dimensions
Dimensions by Area (pels)
1
Page Size Parm
2
Name mm inches A B C D E F G H I
Paper
13, 25 A5 148 x 210 5.83 x 8.27 3496 4960 3196 4720 142 118 0 100 100
12, 45 B5 Paper 182 x 257 7.2 x 10.1 4300 6070 4000 5830 150 120 0 100 100
26 A4 (198 mm)
3
210 x 297 8.3 x 11.7 4960 7014 4676 6778 142 118 0 80 100
26 A4 (203 mm)
3
210 x 297 8.3 x 11.7 4960 7014 4800 6778 80 118 0 80 100
1 Executive 184 x 267 7.25 x 10.5 4350 6300 4050 6060 150 120 0 100 100
2 Letter 216 x 279 8.5 x 11 5100 6600 4800 6360 150 120 0 100 100
3 Legal 216 x 356 8.5 x 14 5100 8400 4800 8160 150 120 0 100 100
101 Universal 216 x 356 8.5 x 14 5100 8400 4800 8160 150 120 0 100 100
Envelope
90 DL 220 x 110 8.66 x 4.33 2598 5196 2314 4960 142 118 0 100 100
91 C5 229 x 162 9.02 x 6.38 3826 5408 3542 5172 142 118 0 100 100
99, 100 B5 Envelope 250 x 176 9.84 x 6.93 4156 5904 3872 5668 142 118 0 100 100
600 Other Envelope 229 x 356 9.02 x 14 5412 8400 4800 8160 150 120 0 100
4
100
80 7-3/4 Monarch 191 x 98 7.5 x 3.875 2326 4500 2024 4260 150 120 0 100 100
89 9 (Com 9) 225 x 98 8.875 x 3.875 2326 5324 2024 5084 150 120 0 100 100
81 10 (Com 10) 241 x 105 9.5 x 4.125 2474 5700 2174 5460 150 120 0 100 100
1
Pel dimensions are for 600 dpi.
2
Page Size Parameters are explained in Table 2-21 on page 2-38.
3
The width of the logical page for A4 paper can be changed from the printer operator panel or through your software
application.
4
The distance from the bottom edge in landscape orientation for Other Envelope is 412 pels.
