PCL
2-10
Optra W810
The following table lists page sizes and print area dimensions for all paper sizes the
Optra W810 printer supports. For more information about the printable areas and
logical pages for PCL emulation, see “Printable Areas” on page 2-2.
Note: The explanation of the printable area assumes the
Print Area menu item is set
to Normal. For more information about Print Area, see page 2-11.
Table 2-7: Optra W810 Paper Dimensions
Selection Paper Dimensions Dimensions by Area (pels)
1
Page Size Parm
2
Name mm inches A B C D E F G H I
13, 25 A5 148 x 210 5.83 x 8.27 3496 4960 3196 4720 142 118 0 100 100
12, 45 B5 Paper 182 x 257 7.2 x 10.1 4300 6070 4000 5830 150 120 0 100 100
26 A4 (198 mm)
3
210 x 297 8.3 x 11.7 4960 7014 4676 6778 142 118 0 80 100
26 A4 (203 mm)
3
210 x 297 8.3 x 11.7 4960 7014 4800 6778 80 118 0 80 100
46 JIS B4 257 x 364 10.1 x 14.3 6070 8600 5786 8362 142 118 0 100 100
27 A3 297 x 420 11.7 x 16.5 7014 9920 6730 9684 142 118 0 100 100
1 Executive 184 x 267 7.25 x 10.5 4350 6300 4050 6060 150 120 0 100 100
2 Letter 216 x 279 8.5 x 11 5100 6600 4800 6360 150 120 0 100 100
3 Legal 216 x 356 8.5 x 14 5100 8400 4800 8160 150 120 0 100 100
6 or 11 11 x 17 (Ledger) 279 x 432 11 x 17 6600 10200 6300 9960 150 120 0 100 100
101 Universal 297 x 432 11.7 x 17 7014 10200 6714 9960 150 120 0 100 100
1
Pel dimensions are for 600 dpi.
2
Page Size Parameters are explained in Table 2-21 on page 2-38.
3
The width of the logical page for A4 paper can be changed from the printer operator panel or through your software
application.
