Example
ȩ {p_1}
Ȩ (PROTOCOL #1 SELECTED!)CrLf
The matrix communicates with Lightware protocol.
INFO: Be aware that different control interfaces can be set to use different protocols. E.g. the Ethernet
interface can use the Lightware protocol while the Serial interface uses Protocol#2 at the same time.
INFO: The Control protocol can be checked with the front panel buttons or in the front panel LCD menu.
DIFFERENCE:
Command and Response
ȩ {ELEVELSEND#<p>= <0>;<1>;<2>;<3>;<4>}
Ȩ (ELEVELSEND#<p>= <0>;<1>;<2>;<3>;<4>)CrLf
Parameters
Parameter description Parameter values
<p> Adjusted control interface 0 = all
1 = RS-232
2 = LAN
3 = USB
<0> 'Notice' level events
0 = no immediate message sent
1 = immediate message
<1>
<2> 'Matter' level events
<3> 'Error' level events
<4> 'Fatal' level events
See the Error Responses section for more information about error levels.
Example
ȩ {elevelsend#0=0;0;1;1;1}
Ȩ (ELEVELSEND#0=0;0;1;1;1)CrLf
Router Status Commands
DIFFERENCE:
Command and Response #label #devicelabel
ȩ {I}
Ȩ ()CrLf
Example
ȩ {i}
Ȩ (I: MX-FR17)CrLf
INFO: Please note that MX-FR65R gives (I:MX-FR80R) response.
The device responds its 8-digit serial number.
Command and Response
ȩ {S}
Ȩ (SN:<SERIAL_NO>)CrLf
Example
ȩ {s}
Ȩ (SN:3C019935)CrLf
Command and Response
ȩ {F}
Ȩ )CrLf
Example
ȩ {f}
Ȩ
<s> string, which may indicate special versions. <s>=r
indicates standard version.
