Lightware MX-FR9 User Manual

11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 169

MX-FR33L
Rack mountable ..............................................................................................................................
Enclosure material ............................................................................................................................ 1 mm steel
Dimensions in mm ............................................................................................................
Dimensions in inch ........................................................................................................
 ...............................................................................................11.6 kg (25.6 lbs)
MX-FR33R
Rack mount .....................................................................................................................................
Enclosure material ............................................................................................................................ 1 mm steel
Dimensions in mm ............................................................................................................
Dimensions in inch ........................................................................................................
 ..........................................................................33.9 kg (74.7 lbs)
 ............................................................................................................ 1 kg (2.2 lbs)
MX-FR65R and MX-FR80R
Rack mountable .............................................................................................................................
Enclosure material ............................................................................................................................ 1 mm steel
Dimensions in mm ............................................................................................................
Dimensions in inch ........................................................................................................
 ..........................................................................27.6 kg (60.8 lbs)
 ......................................................................................................... 1.4 kg (3.1 lbs)
I/O Ports of the MX-CPU2 Board
Inputs
Connectors ................................................................................................................. 29-pole DVI-I digital only
Input cable equalization ............................................................................................................................... No
EDID emulation ............................................................................................................................................ 
Reclocking .................................................................................................................Pixel Accurate Reclocking
Outputs
Connectors .................................................................................................................. 29 pole DVI-I digital only
Output pre-emphasis ..................................................................................................................................... No
Reclocking ................................................................................................................ Pixel Accurate Reclocking
EDID read ....................................................................................................................................................... 
+5V output current ................................................................................. 500 mA continuous each (protected)
Video Inputs - I/O Boards
INFO:  

Connector type ............................................................................................... 19-pole HDMI Type A receptacle
AV standard ............................................................................................................................. DVI 1.0, HDMI 1.4
HDCP compliance ................................................................................................................................ HDCP 1.4
Color space .......................................................................................................................................
Video delay .............................................................................................................................................. 0 frame
 ......... up to 4096x2048@30Hz (4:4:4) or 4096x2048@60Hz (4:2:0)
......................................................................... up to 3840x2160@30Hz (4:4:4) or 3840x2160@60Hz (4:2:0)
................................................................................................... 
Reclocking ................................................................................................................ Pixel Accurate Reclocking
3D support ...................................................................................................................................................... 
Audio formats .............................................................................................................................8 channel PCM
...........................................................................................................Dolby TrueHD, DTS-HD Master Audio 7.1
Input cable equalization .......................................................................................................... 
* All standard VESA, CEA and other custom resolutions up to 300MHz (HDMI1.4) are supported.

Connector type ................................................................................................................................ 29-pole DVI-I
AV standard ............................................................................................................................. DVI 1.0, HDMI 1.4
HDCP compliance ................................................................................................................................ HDCP 1.4
Color space .......................................................................................................................................
Video delay .............................................................................................................................................. 0 frame
 ......... up to 4096x2048@30Hz (4:4:4) or 4096x2048@60Hz (4:2:0)
......................................................................... up to 3840x2160@30Hz (4:4:4) or 3840x2160@60Hz (4:2:0)
................................................................................................... 
Reclocking ................................................................................................................ Pixel Accurate Reclocking
3D support ...................................................................................................................................................... 
* All standard VESA, CEA and other custom resolutions up to 300MHz (HDMI1.4) are supported.




