Driving modes
6.6 Installing/removing the supporting box
Operating Manual GMK6300L 3 112 xxx en 6 - 75
xx.xx.xxxx
6.6.5 Disconnecting/establishing the electrical connection
Separating the connection
• Pull connecting cable (2) and (7) from
sockets (3) and (5).
Insert them into the dummy sockets (1)
and (8).
• Remove the plug (6) from the socket (5) and
plug it into the socket (4).
• Seal sockets (3) and (5) with the protective
caps.
Establishing the connection
• Remove the plug (6) from the socket (4) and
plug it into the socket (5).
• Pull connecting cable (2) and (7) from
dummy sockets (1) and (8).
Insert them into the sockets (3) and (4).
• Seal dummy sockets (1) and (8) with the
protective caps.
S
Risk of malfunctions in the carrier electronics!
Always turn off the ignition before you establish or break the electrical
connection. This prevents malfunctions and error messages in the carrier
electronics.
