Operating elements for crane operation
9.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 9 - 111
xx.xx.xxxx
9.2.22 Lighting, windscreen wiper/washing system
Lighting
Spotlight sockets on/off
Air traffic control light/camera on/off
Rotating beacons on/off
s
– To switch on: Press down – voltage on (both sockets)
– To switch off: Press up – voltage off (both sockets)
– To switch on: Press down – voltage on socket switched on/camera on
– To switch off: Press up – voltage on, socket switched off/camera off
à p. 12 - 112
à Separate operating instructions
– To switch on: Push down – lamp in the button on
– To switch off: Push up – lamp in the button off
