Malfunctions in driving mode
7.5 Fuses
Operating Manual GMK6300L 3 112 xxx en 7 - 19
xx.xx.xxxx
7.5 Fuses
The fuses are divided into groups and are at various points on the carrier:
– In the driver's cab,
– In the battery box.
Information on
replacing fuses
The positions of the fuses, their designations and which functions are
protected by the respective fuses are shown in the following sections.
• Switch off the ignition whenever a fuse has to be replaced.
S
Risk of damage if the ignition is switched on!
Switch off the ignition whenever a fuse has to be replaced. This prevents
the new fuse being blown immediately by the increased starting current
after being installed.
S
Risk of damage by overloading!
Replace blown fuses only with new fuses of the same amperage. This pre-
vent parts being overloaded and damaged or the fuse being immediately
blown again.
Notify Manitowoc Crane Care if a fuse with the same amperage fails again
once the ignition is switched on.
S
Risk of fire!
Never repair a blown fuse with other electrically conductive materials.
