Driving modes
6.6 Installing/removing the supporting box
Operating Manual GMK6300L 3 112 xxx en 6 - 77
xx.xx.xxxx
6.6.7 Attaching/raising the supporting box with the truck crane
Prerequisites:
– The outrigger span 7.98 x 8.50/1.00 m (26.1 x 27.9/3.3 ft) has been estab-
lished and the truck crane is horizontally aligned;
à p. 12 - 46.
– The RCL code for the outrigger span 7.98 x 8.50/1.00 m (26.1 x 27.9/3.3 ft)
as stated in the
Lifting capacity table, has been entered.
– The locking pin on the supporting box has been released;
à p. 6 - 83.
– The electrical, hydraulic, and pneumatic connections are disconnected
before removing the supporting box.
s
S
Risk of damage to the suspension struts and tyres!
Always extend the auxiliary support before you raise the supporting box
with the truck crane.
This prevents the suspension struts and tyres from becoming overloaded
and damaged.
G
Risk of overturning with the raised supporting box!
Always enter an RCL code for the outrigger span 7.98 x 8.50/1.00 m
(26.1 x 27.9/3.3 ft) with the working position required before lifting the sup-
porting box with the truck crane and slewing the truck crane. You may not
override the RCL even if the RCL goes off at a small working radius!
When the working radius increases after RCL shutdown, the stability is no
longer guaranteed.
G
Risk of being crushed when attaching and raising the supporting box!
Always guide the supporting box from the rear with guide ropes when
attaching and raising it. This will help prevent you being crushed between
the supporting box and the carrier.
