Technical Information
50
DG 408x Steam Ovens
Option Setting/Activation Description
INDEX
CONTROL
ELECTRONIC
e.g., EPX 702
ID33795 V.2
The ID number of the control
electronic (2N1) is indicated.
POWER
ELECTRONIC
e.g., EPL 700
ID00796
The ID number of the power
electronic (3N1) is indicated.
FAULT INDEX
“No Faults” or fault code, e.g., “F 01” All faults registered so far are
indicated; refer to Table 060-1.
Delete faults All saved faults are deleted.
FUNCTION TEST
ALL OFF All components are switched off.
HEATING CIRCUIT 1/
STEAM GENERATOR
(1R25)
On Steam generator heater (1R25)
is switched on.
Off Steam generator heater (1R25)
is switched off.
HEATING CIRCUIT 2/
STEAM GENERATOR
(2R25)
On Steam generator heater (2R25)
is switched on.
Off Steam generator heater (2R25)
is switched off.
LOWER HEAT ELEM.
or FLOOR HEATER
On Floor heater R28 is switched on.
Off Floor heater R28 is switched off.
FAN (M2) On The fan (M2) is switched on.
Off The fan (M2) is switched off.
DOOR OPENER (Y56) On The release element (Y56) is
activated and controls the door
opener via a metal rod, which
opens the door a crack.
Off The door closes again slowly.
BUZZER On The buzzer sounds.
Off The buzzer goes silent.
DISPLAY The display alternately lights up
and goes dark.
SENSOR TEST
STEAM GENERATOR
CONTACT or STEAM
GENERATOR
CONTROL
Closed Steam generator is inserted. The
steam generator switch (S84) is
switched on.
Open Steam generator is not inserted.
LEVEL INDICATOR or
FILL INDICATOR
Closed The steam generator is filled.
The level switch (S12) is
switched on.
Open The steam generator is not filled.
DOOR SWITCH Closed Door is closed. Door contact
switch (S4) is switched on.
Open The door is open.
TEMP INTERIOR e.g., 81°F The temperature at the PT 1000
temperature sensor (R30) is
indicated. (F06 if open circuited.)
KEYPAD or FUNCTION PAD PANEL
All keypads, with the exception of
“Timer” and “Off” (DG 4082) or
“Clear” and “Off” (DG 4080), can
be checked by touch.
RUNNING TIME
HEATING CIRCUIT 1 e.g., 0008h The operating hours of heater
1R25 are indicated.
HEATING CIRCUIT 2 e.g., 0008h The operating hours of heater
2R25 are indicated.
LOWER HEAT ELEM.
or FLOOR HEATER
e.g., 0005h The operating hours of heater
R28 are indicated.
DESCALE or NO. OF
DESCALES
e.g., 1 The number of descales
performed is indicated.
Table 060-3: Service Mode
