AS3000™ Service Manual 0070-10-0683 4 - 5
Replacement Parts and Accessories Isometric Drawings
4.3.1.1 Chassis Parts List
FIG. NO. DESCRIPTION PART NUMBER
1 Arm, Monitor 0436-00-0248
2 User Interface Assembly 0997-00-0620 (M31)
021-000026-00 (M32)
115-005982-00 (M33)
3 Aux Gas Assembly 0997-00-0634
4 Channel, Left Side 0436-00-0250
5 Breathing System 115-005967-00
6 Absorber Canister Assembly 0997-00-0629 (original)
115-005724-00 (revised)
7O
2
Flush Valve Assembly 0104-00-0064
8 Scavenger System, AS3000 0992-00-0279
9 Drawer Assembly 0441-00-0206
10 Gauge, N
2
O, Line Pressure 0118-00-0039
11 Gauge,
AIR, Line Pressure 0118-00-0040
12 Gauge, O
2
, Line Pressure 0118-00-0041
13 Gauge, N
2
O High Pressure 0118-00-0042
14 Gauge, AIR High Pressure 0118-00-0036
15 Gauge, O
2
High Pressure 0118-00-0037
16 Switch, Mains (external)
Switch, Mains (internal)
0261-00-0220
0261-00-0218
17 Vaporizer Mount 0997-00-0616
18 Rail, Right Side 0436-00-0251
19 Fuse, 2A, 250V 0159-00-0057
20 Vaporizer Storage Mount 0436-00-0221
21 Fuse, 10A, 250V 0159-00-0058
22 Lock, Key 0366-60-0137
23 Caster, without Brake 0401-00-0054
24 Caster, with Brake 0401-00-0053
25 Tank Wrench Assembly 0367-00-0080
26 Yoke, O
2
0103-00-0676
27 Yoke, AIR 0103-00-0677
28 Yoke, N
2
O 0103-00-0678
29 User Interface Cable 0012-00-1778
30 User Interface Mounting Arm 0436-00-0249
31 Gas Input Assembly 115-006314-00
NS Kit Check Valve 0040-00-0458
NS Not Shown
