AS3000™ Service Manual 0070-10-0683 1 - 29
Theory of Operation Anesthesia System Components
1.6 Anesthesia System Components
1.6.1 Auxiliary Outlets
The AS3000 has four auxiliary outlets (120 VAC, 60 Hz, 2A maximum each). There are
two 2A fuses for each outlet.
1.6.2 Absorber Heater Wire Board
FIGURE 1-20 Absorber Heater Wire Board, Top View
FIGURE 1-21 Absorber Heater Wire Board, Bottom View
1.6.3 Work Light Board
FIGURE 1-22 Work Light Board, Top View
FIGURE 1-23 Work Light Board, Bottom View
