LUBRICATION SYSTEM
9-2
1. Removing lubrication system
Removing lubrication system
Removing sequence
1 Oil filter 3 Oil pressure switch 5 Oil strainer
2 Relief valve 4 Oil pan
5
4
3
2
1
Replace
Replace
Replace
