FUEL SYSTEM
8-5
2. Disassembling, inspecting and reassembling fuel system
2.1 Fuel injection nozzle
2.1.1 Disassembling and inspecting fuel injection nozzle
Disassembling and inspecting fuel injection nozzle
Disassembling sequence
1 Nozzle retaining nut 4 Pin 7 Nozzle holder
2 Nozzle tip assembly 5 Spring
3 Piece 6 Washer
7
6
5
4
3
2
1
Wear
Fatigue and perpendicularity
Wear and damage
Carbon deposit,
clogged injection
nozzle tip
