LUBRICATION SYSTEM
9-6
3. Installing lubrication system
Installing lubrication system
44.1 to 53.9 N·m
{4.5 to 5.5 kgf·m}
[32.5 to 39.8 lbf·ft]
7.85 to 11.8 N·m
{0.8 to 1.2 kgf·m}
[5.8 to 8.7 lbf·ft]
Replace
Replace
Replace
Press oil pan mounting bolt
9.8 to 12.7 N·m {1.0 to 1.3 kgf·m}
[7.2 to 9.4 lbf·ft]
Cast oil pan mounting bolt
24.5 to 30.4 N·m {2.5 to 3.1 kgf·m}
[18.1 to 22.4 lbf·ft]
