INLET AND EXHAUST SYSTEMS
11-2
1. Removing inlet and exhaust systems
1.1 Removing intake cover and exhaust manifold
Removing intake cover and exhaust manifold
Removing sequence
1 Intake pipe 2 Intake cover 3 Exhaust manifold
3
1
2
Replace
Replace
