10.1.2Time required for each processing included in scan time
This section describes how to calculate the processing and execution time described in Section 10.1.1.
(1) I/O refresh time
The I/O refresh time is time required for refreshing I/O data to/from the following modules mounted on the main
base unit and extension base units.
• Input module
• Output module
• Intelligent function module
Calculation method
Use the following expression to calculate the I/O refresh time.
(I/O refresh time) = (number of input points/16) N1 + (number of output points/16) N2
For N1 and N2, refer to Table10.1.
Remark
The number of available base units differs depending on the CPU module.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
Table10.1 I/O refresh time
CPU module
Q3 B, Q3 SB,
Q3 RB, Q3 DB
Q5 B, Q6 B, Q6
RB
Q6 WRB
QA1S5 B,
QA1S6
B
QA6 B,
QA6ADP + A5 B,
QA6ADP + A6 B
N1 N2 N1 N2 N1 N2 N1 N2 N1 N2
Q00JCPU
2.05 s 1.25 s 2.95 s 2.20 s
------Q00CPU
2.00 s 1.20 s 2.75 s 2.05 s
Q01CPU
1.95 s 1.15 s 2.70 s 2.00 s
Q02CPU
2.2 s 1.3 s 2.9 s 2.1 s
--
4.9 s 3.9 s 5.6 s 4.8 s
Q02HCPU, Q06HCPU,
Q12HCPU, Q25HCPU
1.7 s 1.3 s 2.4 s 2.1 s
--
4.3 s 3.9 s 5.0 s 4.8 s
Q02PHCPU, Q06PHCPU,
Q12PHCPU, Q25PHCPU
----
Q12PRHCPU, Q25PRHCPU
2.4 s 2.1 s
