2.2 Detailed description of the inverter
2.2.1 Parts identication for the Mitsubishi
general-purpose inverter FR-E700 series
Inverter model
Serial number
Capacity plate *
Input rating
Output rating
Serial number
Rating plate *
Inverter model
FR - E720 - 1.5 K
Operation panel
Cooling fan
USB connector
(mini-B connector)
Connector for plug-in
option connection
Control circuit
terminal block
Changing the control
logic jumper connector
Main circuit
terminal block
Combed shaped
wiring cover
PU connector
Voltage/current input switch
USB connector cover
Front cover
PU connector cover
* Location of the capacity plate and the rating plate
differs according to the inverter capacity.
Refer to the outline dimension drawing.
FR-E720-1.5K
SERIAL:
XXXXXX
● Accessory
Fan cover fixing screws (M3 × 35mm)
No.
E720
E740
E720S
E710W
Voltage class
Three-phase 200V class
Three-phase 400V class
Single-phase 200V class
Single-phase 100V class
Symbol
None
SC
NF
NC
Control circuit terminal specification
Standard control circuit terminal (screw plug)
Models equipped with Safety Stop functionality
Models equipped with FL remote communication functionality
Models equipped with CC-Link communication functionality
Represents the
inverter capacity [kW]
● Inverter model
