Mitsubishi FREQROL-E700 User Manual

3-2
3.1 Setting basic parameters
3.1.1 Brief description of parameters
Parameters are the values used to congure inverter operation. These are notated as "Pr.". The type and num-
ber of parameters available differ depending on inverter model.
For simple variable-speed operation of the inverter, the initial values of the parameters may be used as they are.
Congure the necessary parameters in accordance with loads and operational specications. Parameters can
be congured, changed, and conrmed from the operation panel.
3.1.2 Typical parameters
Pr. Name Unit Initial value Range Application
0 Torque boost 0.1%
6%/4%/
3%/2%*
0 to 30%
Set when you want to increase a starting torque
or when the motor with a load will not rotate,
resulting in an alarm [OL] and a trip [OC1].
* Initial values differ according to the inverter
capacity. (0.75K or lower/1.5K to 3.7K/5.5K,
7.5K/11K, 15K)
1 Upper-limit frequency 0.01Hz 120Hz 0 to 120Hz
Congure this to set a limit on the maximum
output frequency.
2 Lower-limit frequency 0.01Hz 0Hz 0 to 120Hz
Congure this to set a limit on the minimum out-
put frequency.
3 Base frequency 0.01Hz 60Hz 0 to 400Hz
Congure this when the rate frequency of the
motor is not 60Hz.
Check the motor rating plate.
4
Multi-speed setting
(high speed)
0.01Hz 60Hz 0 to 400Hz
Congure this to change the preset speed
parameter with a terminal.
5
Multi-speed setting
(middle speed)
0.01Hz 30Hz 0 to 400Hz
6
Multi-speed setting
(low speed)
0.01Hz 10Hz 0 to 400Hz
7 Acceleration time 0.1 s 5s/10s/15s* 0 to 3600 s
Acceleration/deceleration time can be set.
* Initial values differ according to the inverter
capacity.
(3.7K or lower/5.5K, 7.5K/11K, 15K)
8 Deceleration time 0.1 s 5s/10s/15s* 0 to 3600 s
9
Electronic thermal O/L
relay
0.01A
Inverter rated
current
0 to 500A
79
Operation mode
selection
1 0
0 External/PU switchover mode
1 Fixed to PU operation mode
2 Fixed to External operation mode
3
External/PU operation mode 1
(Start command from External, frequency com-
mand from PU)
4
External/PU operation mode 2
(Frequency command from External, start com-
mand from PU)
6 Switchover mode
7 External operation mode (PU operation interlock)
Pr.CL Parameter clear 1 0 0, 1
Setting "1" returns all parameters except calibra-
tion parameters to the initial values.
ALLC All parameter clear 1 0 0, 1
Setting "1" returns all parameters to the initial
values.
The following table lists the most commonly used parameters.
● Parameters are congured with initial values so that inverters can operate without specic conguration.
Parameters can be congured in accordance with the motors and devices used in your environment.
POINT
