Mitsubishi MELSEC-Q/L User Manual

38
Category
Instruction Symbol
Symbol Processing Details
Execution
Condition
Number of Basic Steps
Subset
See for Description
BIN 16-bit
Block
data
comparisons
BKCMP=
• This instruction compares BIN 16-bit data
stored in n-point devices starting from the
device specified by S1 with BIN 16-bit
data stored in n-point devices starting
from the device specified by S2, and then
stores the result into the nth device
specified by (D) and up.
5-
Page
182
BKCMP<>
BKCMP>
BKCMP<=
BKCMP<
BKCMP>=
BKCMP=P
BKCMP<>P
BKCMP>P
BKCMP<=P
BKCMP<P
BKCMP>=P
BIN
32-bit block
data
comparisons
DBKCMP=
• This instruction
compares BIN 32-bit data
stored in n-point devices starting from the
device specified by S1 with BIN 32-bit data
stored in n-point devices starting from the
device specified by a constant and S2, and
then stores the result into the nth device
specified by (D) and up.
5-
Page
184
DBKCMP<>
DBKCMP>
DBKCMP<=
DBKCMP<
DBKCMP>=
DBKCMP=P
DBKCMP<>P
DBKCMP>P
DBKCMP<=P
DBKCMP<P
DBKCMP>=P
BKCMP nS1 S2 D
BKCMP
n
S1 S2 D
BKCMP nS1 S2 D
BKCMP nS1 S2 D
BKCMP n
S1 S2 D
BKCMP nS1 S2 D
BKCMP nS1 S2 DP
BKCMP nS1 S2 D P
BKCMP nS1 S2 DP
BKCMP nS1 S2 D P
BKCMP nS1 S2 D
P
BKCMP
nS1 S2 D
P
DBKCMP nS1 S2 D
DBKCMP
nS1 S2 D
DBKCMP nS1 S2 D
DBKCMP nS1 S2 D
DBKCMP n
S1 S2 D
DBKCMP nS1 S2 D
DBKCMP nS1 S2 D
P
DBKCMP
nS1 S2 D P
DBKCMP nS1 S2 D
P
DBKCMP
nS1 S2 D
P
DBKCMP nS1 S2 D
P
DBKCMP
nS1 S2 D
P
