BINDA, BINDAP, DBINDA, DBINDAP
DBINDA
(1) Converts the individual digit numbers of decimal notation of the BIN 32-bit data designated by into ASCII codes, and
stores the results into the area starting from the device designated by .
For example, if the value -12345678 has been designated by , the following would be stored into the area starting from
:
(2) BIN data designated by can be between -2147483648 to 2147483647.
(3) The operations results stored at will be stored in the following way:
(a) The sign "20
H
" will be stored if the BIN data is positive, and the sign "2D
H
" will be stored if it is negative.
(b) The sign "20
H
" will be stored for the leading zeros of effective digits. (Zero suppression is conducted.)
(c) The data stored at the upper 8 bits of the device designated by +5 differs depending on the ON/OFF status of
SM701 (number of characters to output select signal).
When SM701 is OFF.....Stores "0"
When SM701 is ON..... Stores "20
H
"
Operation Error
(1) In the following case, an operation error occurs, the error flag (SM0) turns ON, and an error code is stored into SD0.
Program Example
(1) The following example program uses the PR instruction to output the 16-bit BIN data W0 value by decimal to Y40 to Y48
as ASCII.
[Ladder Mode] [List Mode]
Error
code
Error details
Q00J/
Q00/
Q01
QnH QnPH QnPRH QnU LCPU
4101
The range of the device specified in exceeds the range of the
corresponding device.
–– –– –– ––
S
D
+1
Sign
ASCII code for billions place
ASCII code for hundred-millions place
ASCII code for ten-millions place
b15 b8b7 b0
+2
When SM701 is OFF
When SM701 is ON
ASCII code for millions place
ASCII code for hundred-thousands place
ASCII code for ten-thousands place
ASCII code for thousands place
+3
+1
ASCII code for hundreds place
ASCII code for tens place
ASCII code for units place
0 or 20
H
0
20
H
Upper 16 bits Lower 16 bits
BIN 32-bit data
+4
+5
S
D
S
D
D
D
D
D
S
D
+1
2D
H
()20
H
(space)
20
H
(space)31
H
(1)
b15 b8b7 b0
+2
32
H
(2)33
H
(3)
34
H
(4)35
H
(5)
+3
36
H
(6)37
H
(7)
38
H
(8)
0 or 20
H
+4
+4
+1
12
3
4
5678
S S
D
D
D
D
D
D
S
D
0012
Number of significant digits20
H
034 560
D
D
