Data conversion mode
[13] Data conversion mode
(1) Main data conversion mode functions
The following types of conversion functions can be used on stitching data that has already been input.
Function
Key
Details Details setting
B
data
BA
data
Home
position
correction


The home
position correction
amount can be
set.

Correction Valid
Set No. of stitches

Correction Invalid
○ ○
Back tacking

Existing back
tacking can be
modified, and new
back tacking can
be created.

Start/end back tacking

Overlap back tacking(Valid only for
a closed figure.)
○ ×
Zigzag
stitching

Existing zigzag
stitching can be
modified, and new
zigzag stitching
can be created.
−
○ ×

No. of
Stitches
Fixed
○ ○
Scaling

Scaling with a set
stitch length or set
No. of stitches
can be carried out
independently for
the X axis and Y
axis centering on
the center point.
<Center position>
Jog
Designation
Pattern
Center
Home
position
Center

Fixed Stitch
Length
○ ×
Symmetrical

Using the existing
sewing data,
X-axis, Y-axis, or
XY axis
symmetrical
pattern can be
created. Whether
to keep or delete
the existing
stitching data can
also be selected.
<Methods>
Symmetrical Origin
Clear

Keep Symmetrical
Origin
○ ○
Rotation

The pattern can
be rotated
centering on a
random center
point.
<Center Position>
Jog Designation

Pattern Center

Home position Center

○ ○
Offset

The offset
distance and
direction for offset
stitching data can
be changed.
-
○ ×
Multiple

The multiple
distance, multiple
direction and
number of
multiple stitching
times for multiple
stitching data can
be changed.
-
○ ×
[13]-1
