Program mode list
[17]-1
Tread trimming sensor
S1
Needle thread breakage sensor
valid/invalid
4(3)
S2
Number of stitches to invalidate thread
breakage sensor at stitching start
4(3)
S3
Number of stitches to invalidate needle
thread breakage sensor during stitching
4(3)
B
Needle thread breakage sensor
operation speed setting
4(4)
TST
Thread trimming valid/invalid at needle
thread breakage sensor detection
4(5)
Feed method
WET Work holder weight selection B10
WEL
Setting value for Work holder weight
(WET) = [L] selection
B11
WEM
Setting value for Work holder weight
(WET) = [M] selection
B12
WEH
Setting value for Work holder weight
(WET) = [H] selection
B13
THI Fabric thickness selection B14
TL
Setting value for fabric thickness (THI)
= [L] selection
B15
TM
Setting value for fabric thickness (THI)
= [M] selection
B16
TH
Setting value for fabric thickness (THI)
= [H] selection
B17
FED Feed setting B18
FEM Feed data mode selection B23
FES
Feed data speed simple setting
B24
FSM Smooth feed data setting B25
TYA
Teaching arrow MAX movement
amount (multiplication) setting
X37
Sewing speed
H Maximum speed B38
L Minimum speed B39
M Medium-high speed B40
N Medium-low speed B41
Thread trimming timing
LTM
Thread trimming output (T) output
mode
B27
LLM Thread release output (L) output mode B28
T1
Thread trimming output (T) output start
time/angle
B29
T2
Thread trimming output (T) output
time/end angle
B30
L1
Thread release output (L) output start
time/angle
B31
L2
Thread release output (L) output
time/end angle
B32
T Thread trimming speed B42
ETC
Thread trimming cancel at needle lifting
with needle UP key setting
A6
TRM Thread trimming ON/OFF 4(2)
Step
STE
Step pointer clear at setting table
changeover setting
N2
STO Step operation ON/OFF N1
SUU
Number of execution lines per main
loop
N3
Feed angle
S8 Feed start angle setting B19
E8 Feed end angle setting B20
T8 Feed end angle setting at low speed B21
8D
Angle display from needle DOWN
position
B22
Jog
JGM Jog key function setting A19
UJC
Jog key valid setting at position other
than needle UP position stop
A20
LCD panel
KBC LCD panel buzzer cancel A31
LCD LCD panel connection X29
LOF LCD panel backlight OFF function X30
LNN LCD panel display color X31
LHP Key explanation display X32
KNO Standard mode background selection X33
CTR Key chattering setting X34
CNR LCD panel contrast X35
R LCD panel backlight OFF time X36
Input signal
I1 (*1)[I1] Input function selection C1
I1L (*1)[I1] Input logic changeover C2
I1M (*1)[I1] Input operation selection K1
Output signal
O1 (*1)[O1] Output function selection D1
O1L (*1)[O1] Output logic changeover D2
O1C (*1)[O1] Output chopping function D3
O1M (*1)[O1] Output operation selection 1 L1
O1D (*1)[O1] Output ON delay setting L2
O1E (*1)[O1] Output OFF delay setting L3
1A
(*1)[O1] Setting of delay time to output
ON/pulse output OFF time
L4
1B
(*1)[O1] Setting of ON time/pulse
output ON time
L5
1T
(*1)[O1] Setting of output full wave
output time
L6
1C (*1)[O1] Setting of output chopping duty L7
Miscellaneous
GA Gain high/low changeover function B9
MIL Milling mode ON/OFF N4
APC
Sewing data designation with terminal
block input function
X24
POF
Offset value selection for sewing data
designation with terminal block input
X25
ASC
Maximum speed limit designation with
external input function
X26
AER Error code output with output function X27
PFL Internal memory overwrite prohibit A32
LH
Maximum stitch length for continuous
sewing
X38
LCK
Program Change from Setting Panel
Prohibit Setting
4(6)
PTC
Change in setting table number from
the sewing data
A18
SCP
Permutation of short cut button
B49
DFR
Method of reading the needlework data
from floppy disk (Overwrite / Append)
B50
1 (*1)error code E1
2 (*1)error code E2
3 (*1)error code E3
4 (*1)error code E4
I1 (*1)Input display E5
UP (*1)Input display E30
DN (*1)Input display E31
XH (*1)Input display E32
YH (*1)Input display E33
ECA (*1)Input display E34
ECB (*1)Input display E35
CRS (*1)Input display E36
O1O (*1)Output E37
O1D (*1)Output E61
P (*1) Cumulative power ON time display E85
M (*1) Motor power ON time display E86
DV (*1) Setting table version No. E87
T (*1) Model display E88
BV (*1) System ROM version No. display E89
SV
(*1) System software version No.
display
E90
Special << Do not use >>
