6 - 44
6.10 Intelligent Function Module Switch Setting
6
FUNCTIONS
(4) Precautions
(a) When AnS/A series corresponding module is used
Note6.7
Note7
In switch setting, do not set the AnS/A series corresponding module.
An error ("SP. PARA. ERROR") will occur if switch setting is made to any AnS/A
series corresponding module.
(b) Switch setting of each module
For details on the switch setting for an intelligent function module or interrupt
module, refer to the manual of the intelligent function module or interrupt module.
(c) Setting differences between GX Developer versions
The switch settings for interruption modules with the GX Developer Version 6
(SW6D5C-GPPW-E) or later are made by setting the type to "Interruption".
When using GX Developer version 5 (SW5D5C-GPPW-E) or earlier to set the
interrupt module switches, set the type to "Intelli.".
Refer to the following manual for further details on the interruption module's
switch settings.
Building Block I/O Module User's Manual
(d) Timing when settings are ensured
The switch setting of the intelligent function modules and interrupt modules
become valid in the following cases.
• At power-on of the CPU module
• At reset cancel
Note7
Basic
Process
Redundant
Note6.7
Universal
UD
Note6.7
Note6.7
Note6.7
The Basic model QCPU, Process CPU, Redundant CPU and Universal model QCPU do not
support the AnS/A series corresponding modules.
Basic
Process
Redundant
Universal
UD
Note6.7
Note6.7
Note6.7
Note6.7
