8-190
Schematics, Boards Ove
rlays, and Parts Lists
: Transceiver (RF) Boards: UHF2 (8401243
2001 / PC000354A01)
Figure 8-84. T
ransmitter HF Circuit
10.2NH
10.2NH
10.2NH
6.2PF
3.9PF
IF
IF
100PF
3.3PF
4.7PF
5.6PF
2PF
3.3PF
IF1801
L1803
L1811
L1809
IF1802
C1820
C1821
C1826
C1827
C1822
C1803
C1804
C1807
RF_OUT
HF_OUT
1
1
OUT
IN
445
447
