4-2 Troubleshooting Procedures: Recommended Service Tools
4.2 Recommended Service Tools
Table 4-1 lists recommended service tools that can be used for PC board repairs at the component
level. For listings of additional service tools, service aids, and test equipment that are recommended
for all levels of service, refer to the APX 1000 basic service manual (see Related Publications).
NOTE: Do not place an order for the Programming Cable (PMKN4012A/PMKN4013B) as it is not compatible
with the APX 1000 radio.
Table 4-1. Recommended Service Tools
Motorola
Part Number
Description Application
66012028001 Chassis Opener Used to disassemble chassis from housing
66012031001 Battery Adapter Used in place of battery to connect radio to an external
power supply.
5880384G68 SMA to BNC Adapter Adapts radio’s antenna port to BNC cabling of test
equipment.
RVN5224_ Customer Programming Software
(CPS) and Tuner Software
CPS allows customer-specific programming of modes and
features. Tuner software required to perform alignment of
radio parameters.
PMKN4012B Programming Cable To program the radio through Customer Programming
Software and Tuner Software.
PMKN4013C Programming/Service Cable To program and service the radio through Customer
Programming Software and Tuner Software.
RLN4460_ Portable Test Set For radio performance checks. Connects to radio’s
universal connector and allows remote switching and
signal injection/outputs for test equipment measurements.
TE000008A01 APX1000 Board Debugging Fixture To hold the APX1000 main board in position and provides
necessary connections to the APX1000 front housing kit
for debugging purposes.
