8-20
Disassembly/Reassembly Procedures
: Radio Reasse
mbly
8.6.7
Reassemble the Seal, V
acu
um Port (45†††*), Labe
l Gore Port (43†††) and
Bottom Label (45†††)
1.
Adhere and gently press the Seal, V
acuum Port
(43†††
) on the chassis’ recess as shown in
Figure 8-
26.
Figure 8-26. Assem
ble the Seal, V
acuum Port
2.
With the Seal, V
acuum Port assembled, adh
ere
the Label Gore
Port (43†††) on the chassis’
recess as sh
own in
Figure 8-27.
Figure 8-27. Assemble the Label Go
re Port
V
acuum port seal
105
