Chapter 9 Basic Troubleshooting

This section of the manual contains troubleshooting charts and error codes that will help you to

isolate a problem. Level one and two troubleshooting will support only radio alignment,

programming, battery replacement and circuit board replacement.

Component-level service information can be found in the “ASTRO APX 3000 Portable Radios

Detailed Service Manual,” Motorola publication number 68012007045.

9.1 Power-Up Error Codes

When the radio is turned on (power-up), the radio performs self-tests to determine if its basic

electronics and software are in working order. Problems detected during these tests are presented

as error codes on the radio’s display. For non-display radios, the problem will be presented at

power-up by a single, low-frequency tone. The radio should be sent to the depot if cycling power and

reprogramming the code plug do not solve the problem. The presence of an error should prompt the

user that a problem exists and that a service technician should be contacted.

Self-test errors are classified as either fatal or non-fatal. Fatal errors will inhibit user operation;

non-fatal errors will not. Use Table 9-1 to aid in understanding particular power-up error code

displays.

Table 9-1. Power-Up Error Code Displays

Error

Code

Description Corrective Action

01/02 FLASH ROM Codeplug Checksum Non-Fatal Error Reprogram the codeplug

01/12 Security Partition Checksum Non-Fatal Error Send radio to depot

01/81 Host ROM Checksum Fatal Error Send radio to depot

01/82 FLASH ROM Codeplug Checksum Fatal Error Reprogram the codeplug

01/84 External EEPROM Blank (or SLIC failure) Fatal Error Send radio to depot

01/88 External RAM Fatal Error – Note: Not a checksum failure Send radio to depot

01/90 General Hardware Failure Fatal Error Turn the radio off, then on

01/92 Security Partition Checksum Fatal Error Send radio to depot

01/93 FLASHport Authentication Code Failure Send radio to depot

01/94 Internal EEPROM Blank Fatal Error. Send radio to depot

01/98 Internal RAM Fail Fatal Error Send radio to depot

01/A0 ABACUS Tune Failure Fatal Error Send radio to depot

01/A2 Tuning Codeplug Checksum Fatal Error Send radio to depot

02/81 DSP ROM Checksum Fatal Error Send radio to depot

02/88 DSP RAM Fatal Error – Note: Not a checksum failure Turn the radio off, then on
