Motorola APX 3000 Basic Service Manual

Exploded Views and Parts Lists: APX 3000 Front Kit Exploded View Parts List 10-3
10.2 APX 3000 Front Kit Exploded View Parts List
NOTE:
†
. Items cannot be ordered individually.
††
. RF Board Kit for different bandsplit.
†††
. Items can be ordered individually but they are included in the assembly front kit (0104052J79).
Item
No.
Motorola Part
Number
Description
1
†
13012038001 Bezel. Side
2
†
75012180001 Side Control, Silicon
3
†
11012095001 Mylar, PEN/PET, Adhesive, Seal
4
†
38012038001 Seal, Side Cap
5
†
1014052J58 Assy, Flex, Side Control
6
†
13012039001 Bezel, Top Ctrl
7
†
38012037001 Assy, Emergency Button
8
†
32012209001 Gasket, Emergency
9
†
54012295001 Label, Green Dot
10
†
42012081001 Retainer, Power ON/OFF
11
†
11012104001 Adhesive, Retainer, Power ON/OFF
12
†
5501207001 Lever, Power ON/OFF
13
†
15012208001 Housing Assy, Front
14
†††
0104052J59 Assy, Flex, Top Control
15
†††
41012013001 Spring, Switch, Rotary
16
†
41012014001 Spring, Switch, Rotary, Torque
17
†††
07012048001 Bracket, Top Control
18
†
11012108001 Adhesive, Bluetooth Antenna
19
†
39012077001 Metal Element, Bluetooth Antenna
20
†
54012294001 Label, Front-HSG
21
†
33012027001 Escutcheon, GCAI
22
†
75012118001 Pad, Poron, Coin-cell
23
†
75012183001 Pad, Poron, BTB, 10pin, Plug, Side
24
†
0104052J75 Assy, Flex, Main
