Motorola APX 3000 Basic Service Manual

4-2 Recommended Test Equipment and Service Aids: Service Aids
4.2 Service Aids
Refer to Table 4-2 for a listing and description of the service aids designed specifically for servicing
this family of radios. These kits and/or parts are available from the Radio Products and Solutions
Organization offices listed in Replacement Parts Ordering. While all of these items are available from
Motorola, most are standard shop equipment items, and any equivalent item capable of the same
performance may be substituted for the item listed.
4.3 Field Programming
This family of radios can be aligned and programmed in the field. This requires specific equipment
and special instructions. Refer to the online help in the Customer Programming Software (CPS) for
complete field programming information.
Table 4-2. Service Aids
Motorola Part
Number
Description Application
PMLN6208_ Chassis Opener Used to disassemble chassis from housing.
66012031001 Battery Adapter Used in place of battery to connect radio to an external power
supply.
66012075001 Vacuum Test Fixture Used to connect the vacuum/pressure hose to the radio.
NLN9839_ Vacuum Pump Kit Vacuum pump with gauge and vacuum hose. Requires
Vacuum Test Fixture (66012075001).
5880384G68 SMA to BNC Adapter Adapts radio’s antenna port to BNC cabling of test equipment.
RVN5224_ Customer Programming
Software (CPS) and Tuner
Software
CPS allows customer-specific programming of modes and
features. Tuner software required to perform alignment of
radio parameters.
PMKN4012_ Programming Cable Used to program the radio through Customer Programming
Software and Tuner Software.
PMKN4013_ Programming/Service Cable Used to program and service the radio through Customer
Programming Software and Tuner Software.
RLN4460_ Portable Test Set Used for radio performance checks. Connects to radio’s
universal connector and allows remote switching and signal
injection/outputs for test equipment measurements.
66012036001 APX3000 Covert Board
Debugging Fixture
To be assembled with Flex, Debug (0104055J17), flex,
Extended Main (0104052J79), Assy, Flex, NFC
(0104052J74), front housing kit (0104052J79), and FSTN
Display with Bezel (72012008001).
