8-8
Disassembly/Reassembly Proc
edures
: Radio Disa
ssembly
8.4.4.2
Removal of
the Secondary Shield Assembly (26†††*)
1.
Remove the chassis screws (26†††
*) as shown in
Figure 8-8.
Figure 8-8. Remove the chassis scr
ews
2.
With the chassis screws removed, lif
t the Se
condary Shield Assembly (
26†††*) out from the
Chassis (33†††) as sh
own in
Figure 8-9.
Figure 8-9. Remove the Second
ary Shield Assembly
1
2
3
7
4
5
6
Chassis Screws
Secondary Shi
eld
Secondary Shield
Chassis
93
95
