3.3 Internal Circuit Diagram
3.3.2.2 PNP Open Collector Type (E16P/E32P)
FP0-E16P/E32P
X20
X2n
COM
Y20
(+)
Y2n
Load
Load
5.6 k
Ω
5.6 k
Ω
Internal
circuit
Input side
Output side
Internal
circuit
Internal
circuit
Internal
circuit
(-)
24 V DC
1k
Ω
1k
Ω
24 V DC
(
*
Note)
.
Notes
D
Either positive or negative polarity is possible for the input
voltage supply.
D
The I/O number given above is the I/O number when the
expansion I/O unit is installed as the first expansion unit
(
*
section 5.3).
