Native Instruments MASCHINE MK3 User Manual

The Bank menu showing All Banks for POLYPLEX
The Bank menu allows you to select a particular bank of files for the selected product (POLY-
PLEX in the picture above).
Banks can be additional Libraries (for example MASSIVE Expansions), different versions of the
original Factory Library (for example FM7 Legacy and FM8 Factory Library), or any other con-
tent categorization specific to a particular product (for example different sets of drum sounds
for POLYPLEX, as shown above).
► To select a particular bank for the selected product, click the Bank menu under the prod-
uct icon and choose a bank from the available entries.
→ Upon your selection the Bank menu closes and displays the selected bank. The tag filter
and results list underneath further narrow their content accordingly.
Browser
Searching and Loading Files from the Library
MASCHINE - Manual - 118

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
