Nikon D300 Repair Manual

- R1
･
-
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
Items Judgment standard Remarks
External view
Step
(height difference)
Gap
Btwn top cover & apron: 0.2 mm or less
Other parts: 0.3 mm or less
Moving parts: 0.5 mm or less
Btwn Top cover & Apron: 0.2 mm or less
Btwn Top display panel window (surrounding) & Top cover:
0.45 mm or less
Sub-command dial gap (lower part): 0.3mm ± 0.3 mm or less 0.3mm ± 0.3 mm or less0.3mm ± 0.3 mm or less
SB case & Top cover; SB case & Apron (when built-in
speedlight is stored) : 0.5 mm or less
Btwn Diopter adjusting knob (upper part) & Top cover :
0.7 mm or less
Btwn Metering mode selector dial (upper part) & Top cover :
0.6 mm or less
Other parts: 0.3 mm or less
Moving parts: 0.5 mm or less
Visual check
Digital micrometer
Visual check
Thickness gauge
Size / Force
Shutter release button
Aperture lever
Main mirror
Sub-mirror
∞ Infinity focus
Protrusion: -3.95 ± 0.2 mm
Halfway pressing force: 83 ± 15 g
Halfway pressing stroke: 0.5 ± 0.1 mm
Releasing force: 320 ± 50 g
Releasing stroke: 0.3 ± 0.1 mm ( (Half-release pressing ON)
Extra stroke after releasing button: 0.4 mm or more
Difference btwn Half-releasing and Full pressing force:
235 ± 50g
3.4 height: 3.4 +0.1/-0.05 mm
45 ゜ angle: Up-down ± 10'
Right-left ± 25'
Distortion: 6' or less
Clearance for up-mirror in mirror box: None
Play: 0.2 mm or less
59 ゜ angle: Up-down 0’ +5’/-35’
Right-left ± 20’
Distortion: 8’ or less
±80 μm
Digital micrometer
Tension gauge
3.4 height gauge
Collimator
Main mirror tool
Visual check
Feeling in hand
Sub-mirror tool
Inspection standards
Additional Page
Ｍ
サービス
計画課
Feb.1st.2008
INC

Nikon D300 Specifications

General

Megapixel	12.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	DX
Image stabilizer	No
Total megapixels	13.1 MP
Image sensor size	- \
Image formats supported	JPG, RAW, TIF
Maximum image resolution	4288 x 2848 pixels
Image sensor size (W x H)	23.6 x 15.8 mm
Still image resolution(s)	4288 x 2848, 3216 x 2136, 2144 x 1424
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	51
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Display diagonal	3 \
Vari-angle LCD display	-
Display resolution (numeric)	920000 pixels
Magnification	0.94 x
Product color	Black
Eye relief	19.5 mm
Image editing	Trimming
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Fine, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Zoom
Camera playback	Highlights, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.21
Battery type	EN-EL3e
Battery life (CIPA standard)	1000 shots
Number of batteries supported	1
Flash modes	Auto, Red-eye reduction, Slow synchronization
Flash range (wide)	- m
Compatible memory cards	CF, CF Type II, MicroDrive
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	100, 200, 3200, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
USB version	2.0
Optical zoom	- x
Mounting type	Bayonet
Lens mount interface	Nikon F
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
HD type	Not supported
Maximum video resolution	- pixels
Analog signal format system	NTSC, PAL

Weight and Dimensions

Depth	74 mm
Width	147 mm
Height	114 mm
Weight	825 g
