Nikon D300 Repair Manual

VBA20001-R.3720.A
- Ａ  ・ -
logo�Q0310�forGraphic
070509�Gdesign�ito
6. Required device and conditions
※ AC adapter EH-5 and USB cable (mini B type) UC-E4 are used for all adjustments so they are not
particularly mentioned in the list.
Item Required device Setting/Remarks
1 Gr/Gb difference compensation

・5100K color viewer J63070
(available.)
・Luminance meter BM-3000 J63068
・Tool lens () J61185
・ J63086
Luminance LV13 equivalent
Aperture F5.6
2 Dark current adjustment Body cap
Eyepiece cap or black cloth
3 Sensitivity adjustment
・5100K color viewer J63070
(available.)
・Luminance meter BM-3000 J63068
・Tool lens () J61185
・
・ter (ND8×2)
Luminance LV13 equivalent
Aperture F8
Use a commercial product; 6-step light
reduction
4 Shading adjustment
・5100K color viewer J63070
(available.)
・Luminance meter BM-3000 J63068
・Tool lens () J61185
・ (ND4×2）
Luminance LV13 equivalent
Aperture F5.6
Use a commercial product; 4-step light
reduction
5 Gr/Gb compensation adjustment

/ Line crawl adjustment
・5100K color viewer J63070
(available.)
・Luminance meter BM-3000 J63068
・Tool lens () J61185
・ J63087
・） J63085
Luminance LV13 equivalent
Aperture F5.6
6 Sensitivity ratio adjustment
・ Shutter tester
・Luminance meter BM-3000 J63068
・Tool lens () J61185
・5100K color viewer J63070
(available.)
Luminance LV9

Inspection luminance LV13 equivalent
7 Image shutter inspection and
adjustment
・ Shutter tester
・Luminance meter BM-3000 J63068
・Tool lens () J61185
Luminance LV9,15
Aperture F5.6
8 
black point
・5100K color viewer J63070
(available.)
・Luminance meter BM-3000 J63068
・Tool lens () J61185
Luminance LV13 equivalent
Aperture F5.6
9 
white point
Body cap or Lens cap 
- 25℃
10 TFT adjustment None 
reference value is calculated.
11 Obtain reference value Same as "Sensitivity adjustment" and
"sensitivity ratio adjustment"
12 Initial settings (factory default
settings)
None
13  None
14 Version No./ Serial No. None
★ New tool
INC

Nikon D300 Specifications

General

Megapixel	12.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	DX
Image stabilizer	No
Total megapixels	13.1 MP
Image sensor size	- \
Image formats supported	JPG, RAW, TIF
Maximum image resolution	4288 x 2848 pixels
Image sensor size (W x H)	23.6 x 15.8 mm
Still image resolution(s)	4288 x 2848, 3216 x 2136, 2144 x 1424
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	51
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Display diagonal	3 \
Vari-angle LCD display	-
Display resolution (numeric)	920000 pixels
Magnification	0.94 x
Product color	Black
Eye relief	19.5 mm
Image editing	Trimming
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Fine, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Zoom
Camera playback	Highlights, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.21
Battery type	EN-EL3e
Battery life (CIPA standard)	1000 shots
Number of batteries supported	1
Flash modes	Auto, Red-eye reduction, Slow synchronization
Flash range (wide)	- m
Compatible memory cards	CF, CF Type II, MicroDrive
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	100, 200, 3200, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
USB version	2.0
Optical zoom	- x
Mounting type	Bayonet
Lens mount interface	Nikon F
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
HD type	Not supported
Maximum video resolution	- pixels
Analog signal format system	NTSC, PAL

Weight and Dimensions

Depth	74 mm
Width	147 mm
Height	114 mm
Weight	825 g
