Nikon D300 Repair Manual

VBA20001-R.3720.A
- Ａ  ・ -
logo�Q0310�forGraphic
070509�Gdesign�ito
・
Battery check voltage level adjustment
Connect MB-D10 to the camera for the adjustment.
・


SB. (ref. adjustment software for details)
・
AE accuracy inspection and adjustment
When AE accuracy inspection and adjustment are made,
The following types of lens (AF50/1.4D, AF28/2.8D, AF70-300/4-5.6D or AF-SVR70-300/4-5.6) are used.
Caution:

is displayed on PC screen.
When AE sensor reference values are obtained,set the metering mode to “multi-pattern”.
①
AF accuracy adjustment (Make the overall following adjustment.)
②
YAW, PITCH inspection and adjustment
③ X/Y inspection and adjustment
④
LARK adjustment (inc.
CCD output adjustment)
⑤ AF shift adjustment
〔Tools required〕
・
When adjusting for all adjustment items
ref. Page A26.
1．When inspecting AF accuracy
① AF
adjustment lens (J18266)
②
AF adjusting tool (J15259
）
③
Lens holder for F4 (J15280)
④
AF chart (
J18344）
⑤
Chart illuminator for AF (
J15264)
2．When adjusting YAW, PITCH
YAW, PITCH tool (J18230)
3．When inspecting/adjusting X/Y
AF X/Y chart (J63101)
4．When adjusting LARK
The above tool when inspecting AF accuracy
5．AF shift adjustment
The distance from the bayonet reference plane to the imaging area (CCD) is calculated by the actual shot photo,
and its error is recorded in EEPROM as compensation amount, and adjusted.

"WRITING of AF ADJ. LENS OFFSET VALUE" on the main menu.
《
USB connection communication
》
①
AE CCD alignment inspection and adjustment (ref. Page A27 and 28 for details
）
②
AE accuracy inspection and adjustment
③
Aperture accuracy inspection
④

⑤
Adjustment for battery check level (Use MB-D10 and stabilized power supply.
）
〔Tools required〕ref. Page A26.
AE inspection and adjustment
《
USB connection communication
》
AF inspection and adjustment
《
USB connection communication
》
《
USB connection communication
》
《
USB connection communication
》
《
RS232C connection communication
》
INC
