Nikon D300 Repair Manual

VBA20001-R.3720.A
- Ａ  ・ -
logo�Q0310�forGraphic
070509�Gdesign�ito
#788
#B43
#B44
#1659
#1659
#327
※
Attach [#B43] and [#B44] to the[#B44] to the#B44] to theto the
top cover. Apply the adhesive to the 3
threaded portions
#B43
、
#B44
#B44-side#B43-side
※
       #B43] and [#B44] with the two nuts (#1659),[#B44] with the two nuts (#1659),#B44] with the two nuts (#1659),
and apply the adhesive round the nuts (#1659).(#1659).
Adhesive: Super X
※
Apply the adhesive to the 3 places of the
inside hole where the function-button

※


Positioning
#327
①
Attach the AF-assist lamp protector (#327) to the top cover.
Then, position and attach it temporarily.
②
Apply the adhesive as if covering the inside
of the frame.

Adhesive: Loctite
Adhesive: Super X
Adhesive: Loctite
Adhesive: Super X
INC
