Nikon D300 Repair Manual

VBA20001-R.3720.A
- Ａ  ・ -
logo�Q0310�forGraphic
070509�Gdesign�ito
Caution:
The standard values of the consumption current values are those measured
when the backup battery is fully charged.
ＭＢ－Ｄ１０
Ａ
＋
＋
－
－
12V
＜
Measurement of Consumption current value
＞
When this camera is used for measuring the consumption current value, set the MB-D200 and wire as follows.
* Modify "MS-D10" and connect wires.
Test item Standard Test condition
Main SW
・
OFF
All operational buttons are NOT pushed.

AF50/1.4D, EV12
Main SW
・
ON (Half-release timer OFF) 
Main SW
・
ON (Half-release timer ON) 220 m A or less
Main SW
・
ON (Illumination ON) 250 m A or less
Main SW
・
ON (TFT ON) 300 m A or less
Live view ON 770 m A or less
INC
