Chapter
3
Assembling
This chapter contains the SMZ18/SMZ25 system configuration diagrams and lists of the system components, and explains
how to assemble the systems.
Before starting assembling, read the appropriate notes such as CAUTION “11 Cautions on assembling and installing the
product” at the beginning of this instruction manual and “3 Installation location” in “Notes on Handling the Product” in this
instruction manual.
CAUTION When moving or carrying the system
The SMZ18/SMZ25 system weighs over 20 kg in total.
When moving the assembled microscopy system, work with at least two people. Put hands in the depression at the front of the
base and the rear of both sides to lift up the system. Be very careful not to let fingers be caught when putting it down.
Tools necessary for assembly
Tools Devices that supply tools
Hex wrench (nominal designation: 2.5) Intelligent nosepiece, P-SXY64 XY Stage
Hex wrench (nominal designation: 3) P-SXY64 XY Stage
Hex wrench (nominal designation: 4) Fiber holder
Hex wrench (nominal designation: 5) P-SXY64 XY Stage
Hex wrench (nominal designation: 6) Focus unit
Hex driver (nominal designation: 2) Focus unit, P-PS32 Plain Stand (fit-in type to the top of the support
pillar)
Hex driver (nominal designation: 4) Intelligent nosepiece, Focus mount adapter, Focus mount
Spanner wrench (nominal designation: 10) Fiber holder
To Next Page
