Page 12 AFP-2800 - Fire Indicator Panel – System Description
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
3.6
3.63.6
3.6 C
CC
C
OMPATIBLE
OMPATIBLE OMPATIBLE
OMPATIBLE
B
BB
B
ATTERIES
ATTERIESATTERIES
ATTERIES
In general, any Sealed Lead Acid Battery, or Wet Lead Acid Battery designed for stationary use is compatible with
the AFP2800 Fire Indicator Panel. Automotive batteries must not be used. The use of Nickel Cadmium batteries
is not recommended.
Manufacturer Type Number Voltage Capacity (Ah) Qty Required
Best and Best Sealed LA BP17-12 12 17 2
Best and Best Sealed LA BP24-12 12 24 2
Best and Best Sealed LA BP40-12 12 40 2
NOTE: The batteries could be seriously and permanently damaged if they are permitted to discharge below 20V DC when placed
in series.
3.7
3.73.7
3.7 S
SS
S
YSTEM
YSTEM YSTEM
YSTEM
C
CC
C
APACITY
APACITY APACITY
APACITY
A
AA
A
ND
ND ND
ND
E
EE
E
XPANDABILITY
XPANDABILITYXPANDABILITY
XPANDABILITY
Base System
Item Description Notes
Communications Ring 1 RS485 communications ring to support
Up to 100 Field Modules
Up to 99 Annunciators
8 System Outputs Bell Output
Warning System Output
General Alarm Output
5 Additional programmable relay
outputs
Power Supply 3 Amp power supply and battery
charger
Fused 24VDC outputs
A larger power supply
will be required if total
module load exceeds
2.5A. Power supplies up
to 18A are available.
2 Local AZF’s AZF 1
AZF 2
2 RS232 comms ports Laptop interface
System event printer
Keyboard Interface PS2 QWERTY IBM PC keyboard
System Memory 7500 Named points
5000 Control scripts
4000 History events
System Expansion
Item Description Notes
Ring Expander –
Communications Ring 2
Second RS485 communications ring to
support
Up to an additional 100 Field Modules
Loop Interface Module –
FlashScan
Ring expander module to
communicate with up to 5 x pairs of
Notifier LCM/LEM modules. ie: total of
10 loops of FlashScan.
Each loop of
FlashScan supports
159 Analog/Addressable
Detectors and 159
Addressable Modules
Panel Expansion Relays Up to an additional 8 IFS-803 8-way
relay boards can be added via the
panel serial relay port
