This screen will display a list of all installed rings.
RING 1
RING 2
FLASHSCAN
RING LIST
01 OCT 1999 14:44:37
DOWNUP SELECT
ACTIVE RINGS DETECTED:
USE UP/DOWN BUTTONS TO SELECT A RING:
A = 0
F = 0
I = 0
N = 0
Actions:
Use the UP
and DOWN buttons to scroll through the
list of active rings.
Use the SELECT
button to select the currently
highlighted ring.
S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
– R
– R– R
– R
ING
ING ING
ING
– M
– M– M
– M
ODULE
ODULE ODULE
ODULE
L
LL
L
IST
ISTIST
IST
Once you have selected the ring, the following screen will appear.
MODULES FOUND ON RING 1
001 002 003 004 005 006 007 101 102 103
MODULE LIST
01 OCT 1999 14:44:37
NEXTPREV SELECT
USE BUTTONS TO SELECT A MODULE:
A = 0
F = 0
I = 0
N = 0
Actions:
Use the PREV
and NEXT buttons to scroll through
the list of active modules.
Use the SELECT
button to select the currently
highlighted module.
If the FlashScan ring is selected, you will be taken
directly to the list FlashScan screen (see page 25)
Note: If the module number is displayed with an asterisk (*) beside it, it means the module has been manually programmed in
but never seen.
