AFP-2800 - Fire Indicator Panel – Panel Operation Page 47
©
N
OTIFIER
I
NERTIA
P
TY
L
TD
,
2001
WWW
.
INERTIA
.
COM
.
AU
POINT 1.101.I2 WILL ISOLATE:
POINTS > L1D1 L1D2 L1D3 L1D4;
ISOLATE RANGE
01 OCT 1999 14:44:37
ENTER
Please enter the information below:
A = 0
F = 0
I = 0
N = 1
Actions:
• Use the external QWERTY keyboard to enter in the
points that are to be isolated or de-isolated by the
button press.
Points are to be entered in separated by spaces or
commas and terminated with a semicolon (;)
Press ENTER
once complete.
4.3.5.3
4.3.5.34.3.5.3
4.3.5.3 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
– C
– C– C
– C
ONFIG
ONFIG ONFIG
ONFIG
– M
– M– M
– M
ODULE
ODULE ODULE
ODULE
(A
(A(A
(A
DD
DDDD
DD
/ R
/ R/ R
/ R
EMOVE
EMOVEEMOVE
EMOVE
)
))
)
Overview:
This Config menu is used for adding and removing distributed field modules from the RS485 rings. Even though
the AFP-2800 auto-detects new modules and adds them to the system approximately every 5 minutes. You may
have a module that is not physically installed yet, but you wish to configure its inputs etc. You can use this menu to
Add the module to the system. If the module is not physically found the panel will register a fault but it will still allow
you to set all the parameters.
Similarly, if a module had been physically removed from the system, you can use this menu item to permanently
remove it from the panels memory.
How to Add/Remove modules.
You will first be asked to select the ring (1-4) and then the Add / Remove module menu appears as follows:
MODULES FOUND ON RING 1:
001 002 003 004 005 006 007 101 102 103
ADD/ REMOVE MODULE
01 OCT 1999 14:44:37
NEXTPREV BACK
USE BUTTONS TO SELECT A MODULE:
USE UP/DOWN BUTTONS TO SELECT A RING:
A = 0
F = 0
I = 0
N = 0
ADD REMOVE
To remove a module:
• Use the PREV
and NEXT buttons to scroll
through the list of active modules. Once the desired
module is selected, press the REMOVE
button
once to remove it.
To Add a module:
• Press the ADD
button once.
• You will then prompted to enter a module number to
add.
• You will then be prompted for a module type from
the on screen list of 1-8 ie: (FANC,AZM8,
PAZM8,ACM16AT,ACM32,SCS8, LDM32, LCD80)
• The module has now been added.
