In this screen a Digital Output may be tested to verify it’s ability to operate when required.
POINT STATUS: OFF
DIGITAL OUTPUT TEST MENU
01 OCT 1999 14:44:37
TESTISOL
TESTING DIGITAL OUTPUT POINT
1.2.O3
BACK
TEST BUTTON WILL TOGGLE STATE
A = 0
F = 0
I = 0
N = 1
SCRIPT PROCESSING PAUSED
Action:
• An ISOL
button is provided so that the point can
be easily isolated during the test period, this button
will toggle to DEISOL
if the point is already
isolated.
• A single press of the TEST
button will toggle the
output between On and Off.
• Pressing the BACK
button will return to the
previous screen.
• All Script processing is paused while in test mode to provide positive control of the output state. Script
automatically recommence processing when test mode is exited.
• Test mode will automatically exit after 10 minutes from the last button press to prevent the system remaining
off line.
• If a digital output does not have a control script and is set on during test mode, the output will remain on
permanently until turned off through test mode. This can be a useful function for testing purposes during
commissioning.
Note: As the Dout tests activate the output at the remote module, the module itself is tested as well as the panel to module
communications.
4.3.7.3
4.3.7.34.3.7.3
4.3.7.3 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
– T
– T– T
– T
EST
EST EST
EST
- B
- B- B
- B
ATTERY
ATTERYATTERY
ATTERY
This function will run a load test on the batteries for 15 seconds, and if a battery fault is detected, it will be
displayed and logged as such to the history. A successful Battery Test will clear a battery fault. The panel also
performs a short battery integrity test every hour.
Note: The battery test will not run if there is a Mains Fail condition, so as not to further deplete the battery charge.
