Page 68 AFP-2800 - Fire Indicator Panel – Appendix
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
10 SEPT 12:37 1/2
WEST WING
1.1.Z7 ALARM
A=2 F=2 I=0
Display
The LCD Display is made up of 4 lines of 20 characters each. Events are displayed as:
In the above example, a fault occurred on the 10
th
September at 12:34pm. It is the first of only one fault and
occurred in the East Wing on point number 1.1.Z3. There are 0 alarms, 1 faults, and 0 isolates on the system.
In this example, an alarm occurred on the 10
th
of September
at 12:37pm. It is the first of two alarms and occurred in the
West Wing on point number 1.1.Z7. There are 2 alarms, 2
faults, and 0 isolates on the system.
S
PECIAL
M
ESSAGES
ALL SYSTEMS NORMAL
The system is 100% normal with no alarms, faults, or
isolates.
COMMS FAILURE *
This messages flashes and appears when the LCD80 has not
been polled by the CPU in over 10 seconds
NO RESPONSE FROM CPU
The LCD80 is being polled by the CPU, but the CPU has not
responded to an LCD80 request in over 20 seconds
10 SEPT 12:34 1/1
EAST WING
1.2.Z6 FAULT
A=0 F=1 I=0
Event No / Total Number of Events
Point Status
Total Isolates
Date Time
Point Description
Point / Zone Number
Total Alarms
Total Faults
